mower
The 9GN series mower are suitable for cleaning and slashing of bush and grassland, as well as improving of uneven ranch.
Next:
plow
Technical parameters of mower：
|
Model |
9GN-1.2 |
9GN-1.5 |
9GN-1.8 |
9GN-2.1 |
|
Cutting height（mm） |
25-380 |
|||
|
Cutting width (m) |
1.2 |
1.5 |
1.8 |
2.1 |
|
Width(mm) |
1370 |
1590 |
1960 |
2210 |
|
Length (mm) |
1880 |
2440 |
2770 |
2920 |
|
Height (mm) |
1050 |
1050 |
1050 |
1150 |
|
Weight (kg) |
200 |
260 |
360 |
460 |
|
Working speed(km/h) |
5-8 |
|||
|
Dia. Of crop (mm) |
≤38 |
≤38 |
≤63 |
≤63 |
|
Protection |
|
|||
|
PTO speed |
540 or 760 |
|||
|
linkage |
Three point-mounted |
|||
|
Matched Power (hp) |
15-30 |
25-40 |
30-75 |
40-80 |
