tractor
We can supply 25HP,30HP,40HP, 50HP,60HP,70HP,80HP,90HP,100HP,120HP tractor.
Next:
| Model | ALC304 | ALC354 | ALC404 | ||
| Type | 4*4 | 4*4 | 4*4 | ||
| Meas of Tractor | Lenght (mm) | 2950 | 3000 | 3000 | |
| widht (mm) | 1450 | 1500 | 1500 | ||
| Height (mm) | 1500 | 1500 | 1500 | ||
| Tread | Front (mm) | 1000/1200 | 1000/1200 | 1000/1200 | |
| Rear (mm) | 1000-1200 / 1200-1300 (Adjustable) |
1000-1200 / 1200-1300 (Adjustable) |
1000-1200 / 1200-1300 (Adjustable) |
||
| Wheel base (mm) | 1750 | 1780 | 1780 | ||
| Min.Ground Clearance (mm) | 287 | 287 | 287 | ||
| Net Mass (kg) | 1350 | 1370 | 1380 | ||
| Engine | Model | LD 390 | LD4L22 | LD4L23 | |
| Type | Vertical, water-cooled, diesel | 8Vertical, water-cooled, diesel engine | Vertical, water-cooled, diesel engine | ||
| Number of cylinder(pcs) | 3 | 4 | 4 | ||
| Rated Power (kw / hp) | 22.1 / 30 | 25.7 / 35 | 29.4 / 40 | ||
| Type | Front | 600-16 | 600-16 | 600-16 | |
| Rear | 9.5-24 | 9.5-24 | 9.5-24 | ||
| Clutch | Dry-type, single-acting | Dry-type, single-acting | Dry-type, single-acting | ||
| Steering | Hydraulic power steering | Hydraulic power steering | Hydraulic power steering | ||
| Gear box | （4+1）*2 | （4+1）*2 | （4+1）*2 | ||
| PTO r/min | 720 | 720 | 720 | ||
| Counterweight device | Front6*8Kg Rear2*20Kg | Front8*6Kg Rear2*20Kg | Front8*6Kg Rear2*20Kg | ||
| Steam brake device | Standard equip | Standard equip | Standard equip | ||
