disc harrow

Three kind of disc harrow: light mounted disc harrow, medium hydraulic disc harrow and heavy monted disc harrow.

Contact Supplier

Next: mower

Related Products

Agriculture mach…
- harvester
- tiller
- seeder
- sheller machine
- tractor and acce…
- sprayer
- garden machine
Wood bamboo wor…
- wood grinder
- wood shaving mac…
- wood chipper mac…
- bamboo process m…
Industry machine…
food machine

About Us

Product list

Product Detail

Light-duty Disc Harrow are suitable for pulverized and loosening clods after ploughing and for planning the land before sowing on cultivated land. The machines can make soil and fertilizer mix up, and clear away the stump of plants on light or medium soil and preparing seed bed for planting.

Middle-duty Disc Harrow's front gangs are assembled with scalloped disc, and rear gangs with plain disc. The harrows are adopted a whole frame made of quadrangular steel tubes by welding, So their structures are simple and reasonable, strong and durable. Their processes are perfect. The bearing is ball bearing with sphere-outside and square-inside, its rated load is large, trailing resistance is small, sealing is good.

Technical parameters of Medium duty disc harrow:

Model	1BJ-4.4	1BJ-5.3
Working width(M)	4.4	5.3
Overall size(mm)	297026801460	297032601460
Working depth(mm)	140
Dia. Of Disc(mm)	560
Thickness of disc（mm）	4
Disc spacing(mm)	230
Qty. of Disc	40	48
Productivity(Ha/h)	2.7	3.2
Weight(Kg)	1750	2200
Linkage	Trailed
Matched power(Hp)	80-100	110-150
